PolyFab®
PolyFab Properties
Highly Engineered Embossed Polyethylene Liner
- Resists paints and varnishes
- Long lasting
- Maintains an attractive appearance
UV Stabilized
- Stable in sunlight (UV Stable)
- Tested up to 5,000 kj/m2 with no visible degradation
Resilient Urethane Open-celled Foam
- Resists compression set
- Excellent temperature sealing performance
- Seal conforms to uneven surface
Dual Durometer Insert
- Allows for easy insertion and maximum retention
- It is removable without damaging jamb or seal
Tensile Strength (psi) | 3450 |
压缩形变 | <15% (compressed @ 50% during 22 hours @ 70°C) |
Heat Conductivity W/mK | 0.06 at 0°C |
应用温度 | -60 to 70°C |
Schlegel PolyFab “Passion For Quality”
Reliable Product Delivery and Service
Honed over 40 years, our manufacturing and logistics infrastructure and customer service team operate like well-oiled machines.
PolyFab is a reliable source for high-quality gasket material to meet the weatherstripping and sealing product needs for any size customer including:
- Small renovation contractors
- General contractors
- Large package builders
- Sponsor builders
High-Quality Sealing
PolyFab is a premier line of foam, PP, TPE and dual-extrusion gaskets. From custom windows and doors to office cubicles and other building and product projects, PolyFab sealing products provide consistent quality that is unsurpassed in the industry. All parts shipped from Schlegel EMI are RoHS and REACH compliant.
YOUR SUCCESS IS OUR PRIORITY
Compression Seal Applications
- Window Weatherstripping
- Door Installation
- Workplace Infrastructure
- Construction Screen Installation
Profiles
Profile P4U
Standard Pack: 1600 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P66
Standard Pack: 1200 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile P4E
Standard Pack: 1000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P63
Standard Pack: 1000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile P68
Standard Pack: 650 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile P90
Standard Pack: 3200 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P10
Standard Lengths: 96″ other lengths available upon request
Profile P4P
Standard Pack: 3200 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P41
Standard Lengths: 96″ other lengths available upon request
Fire Rated
Profile P4T
Standard Pack: 3000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P4S
Standard Pack: 3000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile PQ2
Standard Pack: 3000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P4R
Standard Pack: 2000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P53
Standard Lengths: 96″ other lengths available upon request
Profile P4Q
Standard Pack: 2000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile P3W
Standard Pack: 1000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile PH3
Standard Lengths: 96″ other lengths available upon request
Fire Rated
Profile P98
Standard Pack: 1000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P85
Standard Lengths: 96″ other lengths available upon request
Profile P4C
Standard Lengths: 96″ other lengths available upon request
Fire Rated
Profile P32
Standard Pack: 400 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile P3X
Standard Lengths: 96″ other lengths available upon request
Fire Rated
Profile P5A
Standard Pack: 150 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P3Y
Standard Lengths: 96″ other lengths available upon request
Fire Rated
Profile P60
Standard Lengths: 96″ other lengths available upon request
Profile P4F
Standard Pack: 1200 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Fire Rated
Profile P4Y
Standard Lengths: 96″ other lengths available upon request
Profile P5B
Standard Lengths: 96″ other lengths available upon request
Profile P5J
Standard Lengths: 96″ other lengths available upon request
Profile P4X
Standard Pack: 1200 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile P5K
Standard Pack: 2000 ft per reel, 2 reels per carton
Standard Lengths: Cut-to-length available upon request
Profile P5N
Standard Lengths: Cut-to-length available upon request
Profile P4V
Standard Lengths: Cut-to-length available upon request
Profile P4M
Standard Lengths: Cut-to-length available upon request
Profile P4W
Standard Lengths: Cut-to-length available upon request
Profile P4N
Standard Lengths: Cut-to-length available upon request
PolyFab FAQ’s
Yes, we have extensive customization capabilities. We design and manufacture custom extruded components in a variety of shapes and sizes. We offer die-cutting, custom profiles, or custom lengths to better support your designs and increase your application’s long-term performance. Submit your drawing with the desired geometry.
To help meet product orders of all sizes, we have a very low minimum order requirement of only $500 per order. Contact us.
We understand that some projects and requirements only use a small volume of certain product types, so we’re happy to help customers get exactly what they need.
Contact Us today to determine what’s best for you.
Yes. We know that matching up profiles can be tricky. Our samples make it easier to know for sure if you’re ordering the right components. We offer free samples of existing parts. We can send up to 10 feet or five pieces. *
*Lot charge may apply after 10 feet for custom orders. In most cases, the sample is free but in some cases a lot charge may apply (if tooling is required).
The UL 10C Small Scale Fire Endurance & Hose Stream Ratings for Poly are:
P3X: P4U, P4E, P4C, P5A, P3Y, and P4F profiles
P98: P90, P10, P4P, P41, P4T, P4S, PQ2, P4R, P53, P4Q, P3W, and PH3
UL File R40292 Vol. 1
The UL certifications, in addition to the RoHS, WEEE and Reach compliance, will meet or exceed existing customers’ requirements.
After the order has been processed, customers can expect to receive delivery within 4-5 weeks depending on tooling required and quantities ordered. In most cases, customers can choose to expedite delivery for an additional fee. Contact your account manager for details.
Yes. Our inventory management process helps our customers forecast demand and order ahead to decrease lead times. We will customize a program to your specific needs, to maintain a steady flow of incoming parts to your company. Our primary system is Kanban, but we’re not limited to that option. We can work with you to create a custom program that fits your business.
True inventory management requires a partnership between customer and supplier. We work to create an ongoing partnership where we continually work with our customers to meet their needs, control costs, and improve quality.
Speak with your account manager 应用规格
A variety of colors are available to meet your job requirements. Our standard colors are brown, beige, black, and white, and grey.
Yes, we can accommodate your taping needs for most profiles.
